Data sheet
Dimensions & weights
- Wet weight
- 300 kg
- Ground clearance
- 130 mm
- Wheelbase
- 1630 mm
- Payload capacity
- 226 kg
Engine & drivetrain
- Engine
- 1746 cc · Milwaukee-Eight 107
- Cooling
- Air/oil cooled
- Transmission
- 6-speed manual
- Final drive
- Belt
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 18.9 L
Electronics & rider aids
- ABS
- Optional from factory
Consumables & service specs
Every value carries its source.
Tyres
- Front
- 110/90B19 62HFactory front fitment on the cast-wheel configuration.Harley-Davidson identity source · official
- Rear
- 180/70B16 77HFactory rear fitment on the cast-wheel configuration.Harley-Davidson identity source · official
Tyre pressures
- Front — solo
- 32 psi coldHarley-Davidson Recall 0628 corrected the owner-manual value to 32 psi cold.H-D Recall 0628 · official
- Rear — solo
- 40 psi coldExact model-year cold pressure.Harley-Davidson identity source · official
Engine oil
- Viscosity
- SAE 20W-50Use the exact owner-manual temperature table for extreme cold or heat.Harley-Davidson identity source · official
- Capacity
- 4.7 L with filterSet final level using the owner-manual hot-check procedure rather than volume alone.Harley-Davidson identity source · official
Brakes
- Fluid type
- DOT 4Use only fresh DOT 4 from a sealed container.Harley-Davidson identity source · official
Fuel
- Minimum octane
- 91 AKI / 95 RONUnleaded fuel.Harley-Davidson identity source · official
- Ethanol tolerance
- E10 maximum for US-market motorcyclesDo not use E85 or methanol-containing fuel.Harley-Davidson identity source · official
Tyre Library
Tyres for this bike and year
Start with this motorcycle’s front and rear sizes. Open a tyre to check the complete fit for this exact bike and year; a size or original-equipment report alone does not confirm it.
No matching front and rear pair
Michelin Anakee Adventure
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee III
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee Road
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee Wild
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Angel GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Angel GT II
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Angel ST
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventure A41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone Battlax Adventure Trail AT41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventurecross AX41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventurecross Scrambler AX41S
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX BT-45
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX BT46
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Sport Touring T32
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Sport Touring T33
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLE WING BW501 / BW502
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLECRUISE H50
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Avon Cobra Chrome
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Commander II
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Commander III Cruiser
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Commander III Touring
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiClassicAttack
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiEscape
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiLegend
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiMotion
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiRoad
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiRoadAttack 4
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiTour
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiTrailAttack 3
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Cruisetec
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Diablo Powercruiser
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Enduro 3 Sahara
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Enduro Trail-ADV 2
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Enduro Trail-XT+
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Enduro Trail+
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone EXEDRA G853 / G852
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone EXEDRA MAX
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
IRC GP-21F / GP-22R
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Heidenau K60 Scout
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Dunlop K750
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Karoo 4
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Karoo Street
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Lasertec
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler ME 888 Marathon Ultra
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli MT 21 Rallycross
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli MT 60 RS
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Night Dragon
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental RB 2 / K 112
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road 5
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road 6
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road 6 GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road Classic
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road W GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 01
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 01 SE
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 02
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec Z8 Interact
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Scorcher 11
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Scorcher Adventure
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Rally
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Rally STR
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Trail II
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Trail III
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Avon Spirit ST
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Terra Force-R
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 70
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 70 Rocks
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 80
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 80²
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Tourance
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Tourance Next 2
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone Trail Wing TW101 / TW42
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, tube or tubeless setup, a named tyre match.
Does not fit this bike
Michelin Scorcher 31
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, tube or tubeless setup, a named tyre match.
What breaks first and where.
Original owner manual listed the wrong front tyre pressure
MinorCommonHarley-Davidson Recall 0628 corrected the cold front pressure for the FXLR to 32 psi (221 kPa). Keep the correction with the motorcycle and use the corrected value.
Symptoms
- Original owner-manual tyre table shows a different front pressure
Field repairableYes — Set the cold front tyre to 32 psi and retain the official insert with the manual.
Where to find things
Common locations for jacks, filters, fluids and fuse boxes. Follow the reference link when a picture helps more than words.
Engine oil fill
Engine-oil filler plug and dipstick are on the powertrain and are used for the upright hot-level check.
ReferenceBrake fluid reservoir
Front reservoir sight glass is at the handlebar master cylinder; rear reservoir is beside the rear brake system. Both must remain above their minimum marks.
ReferenceBattery
Battery is accessed after seat removal; model equipment around the battery must be moved in the owner-manual sequence.
ReferenceField toolkit
What it takes to remove a wheel, handle common field repairs, and get moving again.
10 lbf drive-belt tension gauge
RequiredCompact inflator with 0-60 psi gauge
RequiredExact-year spare fuse set and puller
RequiredPre-trip-confirmed fastener kit
RequiredTubeless tyre plug kit
Required
