Data sheet
Dimensions & weights
- Wet weight
- 345 kg
- Weight without fuel
- 331.1 kg
- Ground clearance
- 120 mm
- Wheelbase
- 1635 mm
- Payload capacity
- 181 kg
Engine & drivetrain
- Engine
- 1690 cc · Air-cooled Twin Cam 103B
- Cooling
- Air cooled
- Transmission
- 6-speed Cruise Drive manual
- Final drive
- Belt
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 18.9 L
Electronics & rider aids
- Cruise control
- No
- ABS
- Standard
Consumables & service specs
Every value carries its source.
Tyres
- Front
- MT90B16 72HChrome Aluminum Profile Laced wheels with the factory tubeless rim-seal system; preserve the MTM-marked tubeless rim seal and sealed spoke bed.H-D owner manual 2015 · official
- Rear
- 150/80B16 71HChrome Aluminum Profile Laced wheels with the factory tubeless rim-seal system; preserve the MTM-marked tubeless rim seal and sealed spoke bed.H-D owner manual 2015 · official
Tyre pressures
- Front — solo
- 36 psi coldExact model-year cold pressure.H-D owner manual 2015 · official
- Rear — solo
- 40 psi coldExact model-year cold pressure.H-D owner manual 2015 · official
Engine oil
- Viscosity
- SAE 20W-50Use the exact owner-manual temperature table for extreme cold or heat.H-D owner manual 2015 · official
- Capacity
- 2.8 L with filterSet final level using the exact owner-manual hot-check procedure rather than volume alone.Harley-Davidson identity source · official
Brakes
- Fluid type
- DOT 4Use only fresh DOT 4 hydraulic brake fluid from a sealed container.H-D owner manual 2015 · official
Fuel
- Minimum octane
- 91 pump octane (R+M)/2Premium unleaded; 95 RON equivalent.H-D owner manual 2015 · official
