Data sheet
Dimensions & weights
- Wet weight
- 345 kg
- Weight without fuel
- 331.1 kg
- Ground clearance
- 130 mm
- Wheelbase
- 1638 mm
Engine & drivetrain
- Engine
- 1690 cc · Air-cooled balanced Twin Cam 103B, 45-degree V-twin
- Cooling
- Air cooled
- Transmission
- 6-speed Cruise Drive manual
- Final drive
- Belt
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 18.9 L
Electronics & rider aids
- Cruise control
- No
- ABS
- Optional from factory
Consumables & service specs
Every value carries its source.
Tyres
- Front
- MT90B16 72HDunlop D402F on the 16 x 3-inch laced wheel; inner tube and rim flap required.H-D FLSTC parts catalog 2013 · official
- Rear
- 150/80B16 71HDunlop D401 on the 16 x 3-inch laced rear wheel; inner tube and rim flap required.H-D FLSTC parts catalog 2013 · official
Tyre pressures
- Front — solo
- 36 psi coldExact FLSTC solo and two-up front pressure.Harley-Davidson identity source · official
- Rear — solo
- 40 psi coldExact FLSTC rear cold pressure for the standard blackwall fitment.Harley-Davidson identity source · official
Engine oil
- Viscosity
- SAE 20W-50Factory primary recommendation for normal warm-weather operation.Harley-Davidson identity source · official
- Capacity
- 2.8 L with filterExact MY2013 oil-tank capacity with filter; set final level using the hot-check procedure.Harley-Davidson identity source · official
Brakes
- Fluid type
- DOT 4Use only fresh DOT 4 hydraulic brake fluid from a sealed container.Harley-Davidson identity source · official
Fuel
- Minimum octane
- 91 pump octane (R+M)/2Premium unleaded; 95 RON equivalent.Harley-Davidson identity source · official
Tyre Library
Tyres for this bike and year
Start with this motorcycle’s front and rear sizes. Open a tyre to check the complete fit for this exact bike and year; a size or original-equipment report alone does not confirm it.
Sizes match, but more needs checking
Continental ContiTour
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, tube or tubeless setup, a named tyre match.
