Data sheet
Dimensions & weights
- Wet weight
- 228 kg
- Seat height
- 850 mm
- Ground clearance
- 165 mm
- Wheelbase
- 1555 mm
- Suspension travel
- 160 / 160 mm
Engine & drivetrain
- Engine
- 1037 cc · V-twin
- Cooling
- Liquid cooled
- Output
- 101 hp · 100 Nm
- Transmission
- 6-speed
- Final drive
- Chain
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 20.5 L
- Real world range
- 380 km
Electronics & rider aids
- Ride modes
- None
- Cruise control
- Yes
- Traction control
- Yes · defeatable
- ABS
- Yes
- Heated grips
- No
- Heated seat
- No
Service intervals
- Service interval
- 12,000 km
- Valve check
- 24,000 km
Protection
- Bash plate
- None
- Radiator guard
- No
- Oil cooler guard
- No
- Hand guards
- No
Consumables & service specs
Every value carries its source.
Tyres
- Front
- 110/80R19M/C 59VUnchanged from MY2016; tubelessSuzuki OM DL1000A L9 2019 · official
- Rear
- 150/70R17M/C 69VUnchanged from MY2016; tubelessSuzuki OM DL1000A L9 2019 · official
Tyre pressures
- Front — solo
- 250 kPa2.50 kgf/cm2 / 36 psi, cold. Sourced from the DL1000A L9 manual ("ab 2019"), the last full manual republication before MY2020; unchanged carry-forward per Suzuki Austria's manual archive, which lists no newer edition covering 2020 specificallySuzuki OM DL1000A L9 2019 · official
- Rear — solo
- 290 kPa2.90 kgf/cm2 / 42 psi, cold. Carried forward from MY2019 manual (L9); no MY2020-specific manual edition foundSuzuki OM DL1000A L9 2019 · official
- Front — loaded
- 250 kPaManual states identical value for solo and passenger (Sozius) riding; carried forward from MY2019 manualSuzuki OM DL1000A L9 2019 · official
- Rear — loaded
- 290 kPaManual states identical value for solo and passenger (Sozius) riding; carried forward from MY2019 manualSuzuki OM DL1000A L9 2019 · official
Engine oil
- Viscosity
- SAE 10W-40Unchanged from MY2016; engine carried forward per brief guidance (2016-2020 DL1000/DL1000A share the 1037cc V-twin)Suzuki OM DL1000A L9 2019 · official
- Capacity
- 3.1 lWith oil filter change (2700 ml oil-only change); unchanged from MY2016 manual valueSuzuki OM DL1000A L9 2019 · official
- Filter part no.
- 09915-40620Unchanged from MY2016 manualSuzuki OM DL1000A L9 2019 · official
Coolant
- Type
- SUZUKI SUPER LONG LIFE COOLANT (blue) or SUZUKI LONG LIFE COOLANT (green); or aluminum-radiator-compatible glycol-based antifreeze mixed 50:50 with distilled waterSuzuki OM DL1000A L9 2019 · official
- Capacity
- 2.13 lUnchanged from MY2016Suzuki OM DL1000A L9 2019 · official
Brakes
- Fluid type
- DOT 4From a sealed container, per manualSuzuki OM DL1000A L9 2019 · official
Final drive
- Chain
- RK525SMOZ8, 116 linksUnchanged from MY2016Suzuki OM DL1000A L9 2019 · official
Spark plugs
- Type
- NGK LMAR8BI-9Unchanged from MY2016Suzuki OM DL1000A L9 2019 · official
- Gap
- 0.8-0.9 mmUnchanged from MY2016Suzuki OM DL1000A L9 2019 · official
- Quantity
- 2Inferred from 90-degree V-twin, 2-cylinder engine; not explicitly restated as a standalone fieldSuzuki OM DL1000A L9 2019 · official
Battery
- Type
- 12V 40.3 kC (11.2 Ah)/10 HRSlightly different capacity rating vs MY2016 manual (12 Ah); manual also references "MF battery of original type" for serviceSuzuki OM DL1000A L9 2019 · official
Fuel
- Minimum octane
- 95 RONUnleaded premium fuel, RON 95 or higher; Canada minimum pump octane 90 (R+M)/2 method per manualSuzuki OM DL1000A L9 2019 · official
