Data sheet

Dimensions & weights

Wet weight: 206.9 kg
Seat height: 890 mm
Ground clearance: 211 mm
Wheelbase: 1540 mm
Suspension travel: 200 / 185 mm

Engine & drivetrain

Engine: 652 cc · 652cc 4-stroke, liquid-cooled, DOHC, 4-valve, single cylinder
Cooling: Liquid cooled
Output: 40 hp · 52 Nm
Transmission: 5-speed, return shift, wet multi-disc manual clutch
Final drive: Chain
Fuelling: Electronic fuel injection

Fuel & range

Fuel capacity: 23 L
Real world range: 360 km

Electronics & rider aids

Ride modes: None
Cruise control: No
Traction control: No
ABS: Yes
Heated grips: No
Heated seat: No

Service intervals

Service interval: 12,000 km / 12 months
Valve check: 15,000 km
Chain lube: every 800 km
Air filter: 24,000 km

Protection

Bash plate: None
Radiator guard: No
Oil cooler guard: No
Hand guards: No

Consumables & service specs

Every value carries its source.

Tyres

Front: 90/90-21Kawasaki official · official
Rear: 130/80-17Kawasaki official · official

Tyre pressures

Front — solo: 21 psi150 kPa / 1.5 bar / 21 psi, for loads up to 97.5 kg (215 lb). Many riders run ~29 psi front for better on-road handling.KLR650 maintenance schedule
Rear — solo: 21 psi150 kPa / 1.5 bar / 21 psi, for loads up to 97.5 kg (215 lb).KLR650 maintenance schedule
Front — loaded: 36 psi250 kPa / 2.5 bar / 36 psi, for loads above 97.5 kg (215 lb).KLR650 maintenance schedule
Rear — loaded: 36 psi250 kPa / 2.5 bar / 36 psi, for loads above 97.5 kg (215 lb).KLR650 maintenance schedule

Engine oil

Viscosity: 10W-4010W-50 acceptable in warmer climates; API SG or above and JASO MA/MA2 for the wet clutch.KLR650 maintenance schedule
Capacity: 2.0 L~2.0 L (2.1 US qt) with filter per hands-on 2022 oil-change guidance; Wikipedia lists 2.5 L nominal. Fill to sight glass — do not overfill.Wikipedia
Filter part no.: TK03441BKawasaki genuine Gen 3 cartridge; classic KLR cartridge 16099-004 (Hiflofiltro HF123, K&N KN-123) also fits 2022+.KLR650 maintenance schedule

Coolant

Type: Permanent-type ethylene-glycol antifreeze, OAT/silicate-free, corrosion inhibitors safe for aluminium enginesKLR650 maintenance schedule
Capacity: 1.3 L~1.3 L (1.4 qt) confirmed by hands-on refill.Community forums

Brakes

Fluid type: DOT 4Front and rear; explicit DOT grade not printed on fetched Gen 3 sources but DOT 4 is the KLR-standard fluid.KLR650 maintenance schedule

Forks

Oil viscosity: 10WStock 41mm fork carried over from Gen 2.Wikipedia
Oil capacity: 500 ml~500 cc (16.9 oz) per leg. Aftermarket monotube cartridges use less (230 cc).Wikipedia

Final drive

Chain: 520 sealed chainMatch any carried master link to the fitted chain manufacturer and model; do not rely on pitch alone.Kawasaki official · official

Spark plugs

Type: NGK CPR8EA-9Kawasaki OEM part 92070-0029. Some catalogs still list the older DPR8EA-9 (physically compatible heat range) for 2022+, but OEM for the DFI Gen 3 is CPR8EA-9.Wikipedia
Gap: 0.9 mmWikipedia
Quantity: 1Wikipedia

Battery

Type: YTX9-BS / FTX9-BSSiam Furukawa FTX9-BS OEM, sealed AGM.KLR650 maintenance schedule
Capacity: 8 Ah12V 8 Ah.KLR650 maintenance schedule

Fuel

Fuel type: Unleaded petrolKawasaki official · official
Minimum octane: 87 AKI / 91 RON minimumClean fresh unleaded gasoline; up to 10% ethanol.Kawasaki 2022 KLR650 owner manual · official

Tyre Library

Tyres for this bike and year

Start with this motorcycle’s front and rear sizes. Open a tyre to check the complete fit for this exact bike and year; a size or original-equipment report alone does not confirm it.

Search these sizes

Matches this bike and year

Dunlop K750

The manufacturer lists this exact front and rear tyre pair for the selected motorcycle and year. Any details the source does not publish separately remain visible below.

Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup.

manufacturer fact: Kawasaki's factory catalogue identifies the exact Dunlop K750 front and rear pair and matching tubes.

Sizes match, but more needs checking

Michelin Anakee Adventure

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Michelin Anakee Wild

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Bridgestone Battlax Adventure Trail AT41

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Bridgestone BATTLAX Adventurecross AX41

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Bridgestone BATTLAX BT-45

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Bridgestone BATTLAX BT46

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Continental ContiEscape

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Continental ContiTrailAttack 3

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Metzeler Enduro 3 Sahara

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Mitas Enduro Trail-XT+

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Heidenau K60 Scout

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Metzeler Karoo 4

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Pirelli Scorpion Rally STR

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Pirelli Scorpion Trail II

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Mitas Terra Force-R

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Continental TKC 70

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.

Sizes match, but more needs checking

Continental TKC 80²

Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.

Still needs checking: construction, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
