Data sheet
Dimensions & weights
- Weight without fuel
- 285 kg
- Ground clearance
- 142 mm
- Wheelbase
- 1630 mm
Engine & drivetrain
- Engine
- 1450 cc · Twin Cam 88, 45-degree air-cooled V-twin
- Cooling
- Air/oil cooled
- Transmission
- 6-speed Cruise Drive manual
- Final drive
- Belt
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 17.8 L
Electronics & rider aids
- ABS
- Not fitted
Consumables & service specs
Every value carries its source.
Tyres
- Front
- 100/90-19Factory Dunlop D401F fitment on the exact FXDBI 19-inch steel laced wheel; inner tube and rim flap required.H-D Dyna parts catalog 2006 · official
- Rear
- 160/70B17Factory Dunlop K591 fitment on the exact FXDBI 17-inch steel laced wheel; inner tube and rim strip required.H-D Dyna parts catalog 2006 · official
Tyre pressures
- Front — solo
- 30 psi coldFactory solo and two-up front pressure.Harley-Davidson identity source · official
- Rear — solo
- 36 psi coldFactory solo pressure; use 40 psi with a passenger.Harley-Davidson identity source · official
Engine oil
- Viscosity
- SAE 20W-50Factory primary recommendation for normal ambient temperatures.Harley-Davidson identity source · official
- Capacity
- 2.8 L with filterOil-tank capacity with filter; finish with the manual's hot-level check.Harley-Davidson identity source · official
Brakes
- Fluid type
- DOT 4Use only fresh DOT 4 fluid and never mix hydraulic-fluid grades.Harley-Davidson identity source · official
Fuel
- Minimum octane
- 91 AKI / 95 RONPremium unleaded fuel.Harley-Davidson identity source · official
Tyre Library
Tyres for this bike and year
Start with this motorcycle’s front and rear sizes. Open a tyre to check the complete fit for this exact bike and year; a size or original-equipment report alone does not confirm it.
Sizes match, but more needs checking
Continental ContiTour
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee Adventure
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee III
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee Road
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Anakee Wild
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Angel GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Angel GT II
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Angel ST
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventure A41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone Battlax Adventure Trail AT41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventurecross AX41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventurecross Scrambler AX41S
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX BT-45
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX BT46
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Sport Touring T32
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Sport Touring T33
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLE WING BW501 / BW502
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone BATTLECRUISE H50
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Commander III Cruiser
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Commander III Touring
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiClassicAttack
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiEscape
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiLegend
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiMotion
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiRoad
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiRoadAttack 4
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental ContiTrailAttack 3
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Enduro 3 Sahara
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Enduro Trail-ADV 2
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Enduro Trail-XT+
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Enduro Trail+
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone EXEDRA G853 / G852
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone EXEDRA MAX
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
IRC GP-21F / GP-22R
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Heidenau K60 Scout
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Dunlop K750
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Karoo 4
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Karoo Street
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Lasertec
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler ME 888 Marathon Ultra
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli MT 21 Rallycross
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli MT 60 RS
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental RB 2 / K 112
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road 5
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road 6
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road 6 GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road Classic
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Road W GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 01
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 01 SE
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 02
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Roadtec Z8 Interact
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Scorcher 11
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Michelin Scorcher Adventure
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Rally
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Rally STR
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Trail II
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Pirelli Scorpion Trail III
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Avon Spirit ST
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Mitas Terra Force-R
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 70
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 70 Rocks
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 80
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Continental TKC 80²
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Tourance
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Metzeler Tourance Next 2
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
No matching front and rear pair
Bridgestone Trail Wing TW101 / TW42
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: construction, load rating, any manufacturer restrictions, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Does not fit this bike
Avon Cobra Chrome
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Does not fit this bike
Michelin Commander II
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Does not fit this bike
Metzeler Cruisetec
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Does not fit this bike
Pirelli Diablo Powercruiser
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Does not fit this bike
Pirelli Night Dragon
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Does not fit this bike
Michelin Scorcher 31
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: construction, source information, load rating, any manufacturer restrictions, front and rear pairing, approved rim width, speed rating, tube or tubeless setup, a named tyre match.
Where to find things
Common locations for jacks, filters, fluids and fuse boxes. Follow the reference link when a picture helps more than words.
Engine oil fill
Engine-oil filler plug and dipstick are on the oil tank at the right side of the powertrain.
ReferenceBrake fluid reservoir
Front reservoir is at the handlebar master cylinder; rear reservoir is beside the rear master cylinder.
ReferenceBattery
Battery is beneath the seat; disconnect the negative lead first and reconnect it last.
ReferenceField toolkit
What it takes to remove a wheel, handle common field repairs, and get moving again.
1 1/8-inch rear axle-nut socket
Required10 lbf drive-belt tension gauge
Required10 mm twelve-point caliper socket
Required100/90-19 spare front inner tube
Required160/70B17 spare rear inner tube
Required20-100 ft-lb torque wrench
Required3/4-inch axle-nut socket
Required5 mm hex-bit socket
Required7/16-inch alignment pin
RequiredCompact inflator with 0-60 psi gauge
RequiredExact-year spare fuse set and puller
RequiredThree motorcycle tyre levers and two rim protectors
RequiredTube patch kit, vulcanising cement and valve-core tool
Required
