Data sheet
Dimensions & weights
- Wet weight
- 330 kg
- Ground clearance
- 120 mm
- Wheelbase
- 1630 mm
- Payload capacity
- 196 kg
Engine & drivetrain
- Engine
- 1923 cc · Milwaukee-Eight 117 Classic
- Cooling
- Air/oil cooled
- Output
- 98 hp · 163 Nm
- Transmission
- 6-speed manual
- Final drive
- Belt
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 18.9 L
Electronics & rider aids
- Cruise control
- Yes
- ABS
- Standard
Consumables & service specs
Every value carries its source.
Tyres
- Front
- 130/90B16 73HFactory tyre size; confirm tube requirement from the fitted wheel and tyre marking because factory cast and laced wheel availability varies by trim and year.Harley-Davidson identity source · official
- Rear
- 150/80B16 77HFactory tyre size; confirm tube requirement from the fitted wheel and tyre marking because factory cast and laced wheel availability varies by trim and year.Harley-Davidson identity source · official
Tyre pressures
- Front — solo
- 36 psi cold at 20 C / 68 FRecheck the manual temperature-adjustment table when ambient temperature is above 20 C.Harley-Davidson identity source · official
- Rear — solo
- 40 psi cold at 20 C / 68 FRecheck the manual temperature-adjustment table when ambient temperature is above 20 C.Harley-Davidson identity source · official
Engine oil
- Viscosity
- SAE 20W-50Factory-fill viscosity for normal operating conditions; use the owner-manual temperature table for extreme cold or heat.Harley-Davidson identity source · official
- Capacity
- 4.7 L with filterFactory model-page capacity is 5 US qt; verify level using the hot-check procedure rather than volume alone.H-D FLHC spec 2025 · official
Brakes
- Fluid type
- DOT 4Use only fresh DOT 4 from a sealed container.Harley-Davidson identity source · official
Fuel
- Minimum octane
- 91 AKI / 95 RONUnleaded fuel.Harley-Davidson identity source · official
- Ethanol tolerance
- E10 maximum for US-market motorcyclesDo not use E85 or methanol-containing fuel.Harley-Davidson identity source · official
