Data sheet
Dimensions & weights
- Wet weight
- 299 kg
- Ground clearance
- 210 mm
- Wheelbase
- 1585 mm
- Payload capacity
- 156 kg
Engine & drivetrain
- Engine
- 1252 cc · Revolution Max 1250
- Cooling
- Liquid cooled
- Output
- 150 hp · 128 Nm
- Transmission
- 6-speed manual
- Final drive
- Chain
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 21.2 L
Electronics & rider aids
- Cruise control
- Yes
- ABS
- Yes
Consumables & service specs
Every value carries its source.
Tyres
- Front
- 120/70R19 60VFactory front fitment; tubeless wheel.Harley-Davidson identity source · official
- Rear
- 170/60R17 72VFactory rear fitment; tubeless wheel.Harley-Davidson identity source · official
Tyre pressures
- Front — solo
- 36 psi cold at 20 C / 68 FFactory cold pressure; the motorcycle tyre-information label remains the final check at the wheel.Harley-Davidson identity source · official
- Rear — solo
- 42 psi cold at 20 C / 68 FFactory cold pressure; the motorcycle tyre-information label remains the final check at the wheel.Harley-Davidson identity source · official
Engine oil
- Viscosity
- SAE 15W-50Factory preferred normal-condition viscosity.Harley-Davidson identity source · official
- Capacity
- 4.5 LTotal engine-oil capacity; the service oil change is 3.8 L.Harley-Davidson identity source · official
Coolant
- Type
- Genuine Harley-Davidson Extended Life Antifreeze and CoolantDo not open the cooling system hot.Harley-Davidson identity source · official
- Capacity
- 2.2 LFactory cooling-system capacity.Harley-Davidson identity source · official
Brakes
- Fluid type
- DOT 4Use only fresh fluid from a sealed container.Harley-Davidson identity source · official
Final drive
- Chain
- 525Use a matching 525 chain and master link.Harley-Davidson identity source · official
Fuel
- Minimum octane
- 91 AKI / 95 RONPremium unleaded fuel.Harley-Davidson identity source · official
- Ethanol tolerance
- E10 maximum for US-market motorcyclesDo not use E85 or methanol-containing fuel.Harley-Davidson identity source · official
Tyre Library
Tyres for this bike and year
Start with this motorcycle’s front and rear sizes. Open a tyre to check the complete fit for this exact bike and year; a size or original-equipment report alone does not confirm it.
Sizes match, but more needs checking
Michelin Anakee Adventure
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Michelin Anakee III
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Michelin Anakee Road
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Pirelli Angel GT II
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Bridgestone BATTLAX Adventure A41
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Bridgestone Battlax Adventure Trail AT41
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Continental ContiRoadAttack 4
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Continental ContiTrailAttack 3
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Mitas Enduro Trail-ADV 2
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Metzeler Karoo Street
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Metzeler ME 888 Marathon Ultra
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Michelin Road 6
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Metzeler Roadtec 02
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Michelin Scorcher Adventure
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Pirelli Scorpion Rally STR
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Pirelli Scorpion Trail II
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Pirelli Scorpion Trail III
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Avon Spirit ST
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Mitas Terra Force-R
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Continental TKC 70
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Sizes match, but more needs checking
Metzeler Tourance Next 2
Matching front and rear sizes exist, but some motorcycle requirements or the front-and-rear pairing still need confirmation.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
No matching front and rear pair
Pirelli Angel GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Pirelli Angel ST
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Adventurecross AX41
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX BT-45
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX BT46
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Sport Touring T32
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLAX Sport Touring T33
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLE WING BW501 / BW502
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone BATTLECRUISE H50
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Avon Cobra Chrome
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Commander II
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Commander III Cruiser
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Commander III Touring
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental ContiClassicAttack
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental ContiEscape
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental ContiLegend
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental ContiMotion
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental ContiRoad
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental ContiTour
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Cruisetec
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Pirelli Diablo Powercruiser
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Enduro 3 Sahara
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone EXEDRA G853 / G852
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone EXEDRA MAX
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
IRC GP-21F / GP-22R
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Dunlop K750
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Lasertec
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Pirelli MT 21 Rallycross
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Pirelli MT 60 RS
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Pirelli Night Dragon
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental RB 2 / K 112
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Road 5
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Road 6 GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Road Classic
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Road W GT
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 01
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Roadtec 01 SE
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Roadtec Z8 Interact
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Scorcher 11
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Michelin Scorcher 31
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental TKC 70 Rocks
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Continental TKC 80
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Metzeler Tourance
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
No matching front and rear pair
Bridgestone Trail Wing TW101 / TW42
No complete front and rear size pair in this tyre range matches the selected bike and year.
Still needs checking: any manufacturer restrictions, approved rim width, a named tyre match.
Does not fit this bike
Michelin Anakee Wild
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Bridgestone BATTLAX Adventurecross Scrambler AX41S
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Mitas Enduro Trail-XT+
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Mitas Enduro Trail+
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Heidenau K60 Scout
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Metzeler Karoo 4
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Pirelli Scorpion Rally
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Does not fit this bike
Continental TKC 80²
The size names match, but one or more complete fit checks fail for this motorcycle.
Still needs checking: source information, any manufacturer restrictions, front and rear pairing, approved rim width, a named tyre match.
Where to find things
Common locations for jacks, filters, fluids and fuse boxes. Follow the reference link when a picture helps more than words.
Engine oil fill
Engine-oil filler and level-check point are on the powertrain; use the owner-manual warm-engine level procedure.
ReferenceCoolant reservoir
Coolant reservoir is serviced through its plug and dipstick only when the engine and cooling system are completely cold.
ReferenceBrake fluid reservoir
Front reservoir is at the handlebar master cylinder; rear reservoir is adjacent to the rear-brake system. Keep levels above their minimum marks.
ReferenceAir filter housing
Air-cleaner housing is mounted at the engine intake; inspect its seal and element after dusty running.
ReferenceFuse box — interior
The 40 A main fuse is behind the right steering-head cover; the accessory fuse block is beneath the rider seat.
ReferenceField toolkit
What it takes to remove a wheel, handle common field repairs, and get moving again.
Compact inflator with 0-60 psi gauge
RequiredPre-trip-confirmed fastener kit
RequiredTubeless tyre plug kit
Required
