Data sheet
Dimensions & weights
- Wet weight
- 263 kg
- Seat height
- 890 / 910 mm
- Wheelbase
- 1510 mm
- Suspension travel
- 190 / 200 mm
- Payload capacity
- 217 kg
Engine & drivetrain
- Engine
- 1170 cc · Boxer twin
- Cooling
- Liquid cooled
- Output
- 125 hp · 125 Nm
- Transmission
- 6-speed
- Final drive
- Shaft
- Fuelling
- Electronic fuel injection
Fuel & range
- Fuel capacity
- 30 L
- Real world range
- 508 km
Electronics & rider aids
- Ride modes
- Rain/Road/Dynamic/Enduro
- Cruise control
- Yes
- Traction control
- Yes · defeatable
- ABS
- Yes · fully defeatable
- Heated grips
- Yes
- Heated seat
- No
Service intervals
- Service interval
- 10,000 km
- Valve check
- 20,000 km
Protection
- Bash plate
- Partial engine
- Radiator guard
- No
- Oil cooler guard
- No
- Hand guards
- Yes
Consumables & service specs
Every value carries its source.
Tyres
- Front
- 120/70 R19BMW OM R1200GSA 2016 · official
- Rear
- 170/60 R17BMW OM R1200GSA 2016 · official
Tyre pressures
- Front — solo
- 2.5 barTyre cold; BMW does not publish a separate solo pressure — this is the single stated front pressureBMW OM R1200GSA 2016 · official
- Rear — solo
- 2.9 barTyre cold; BMW does not publish a separate solo pressure — this is the single stated rear pressureBMW OM R1200GSA 2016 · official
Engine oil
- Viscosity
- SAE 5W-40API SL / JASO MA2; BMW recommends BMW Motorrad ADVANTEC Ultimate oil; molybdenum-based additives not permitted (coated engine components)BMW OM R1200GSA 2016 · official
- Capacity
- 4.0 lMax, with filter change; MIN-to-MAX top-up difference approx. 0.95 lBMW OM R1200GSA 2016 · official
Coolant
- Type
- BMW Motorrad-approved antifreeze with corrosion inhibitorUse compatible coolant; do not mix incompatible coolant chemistries.R1200GS LC service coolant data
- Capacity
- 1.5 lComplete cooling circuit; expansion tank capacity 0.25 L.R1200GS LC service coolant data
Brakes
- Fluid type
- DOT 4Front and rearBMW OM R1200GSA 2016 · official
Final drive
- Shaft oil grade
- Shaft drive with bevel gears (cardan), single-sided BMW EVO Paralever swingarm, gear ratio 2.91 (32/11 teeth)BMW OM R1200GS 2017 · official
- Shaft oil capacity
- 180 ml180 ml for oil change on 2010+ wethead-era final drives (fill via dedicated fill hole, not speed sensor hole); community-sourced corroborationADVrider final drive capacity thread
Spark plugs
- Type
- NGK LMAR8D-JBMW OM R1200GSA 2016 · official
- Gap
- 0.8 mm0.8±0.1 mm when new; 1.0 mm wear limitBMW OM R1200GSA 2016 · official
- Quantity
- 2One per cylinder, boxer twinBMW OM R1200GSA 2016 · official
Battery
- Type
- AGM (Absorbent Glass Mat), 12V 12Ah maintenance-freeBMW OM R1200GSA 2016 · official
Fuel
- Minimum octane
- 91 RON / 87 AKI (regular unleaded, power/consumption restricted); 95 RON / 89 AKI recommended (premium unleaded)BMW OM R1200GSA 2016 · official
- Ethanol tolerance
- Max. 10% ethanol (E10)E85/Flex Fuel not permittedBMW OM R1200GSA 2016 · official
